Autel MaxiSys MS906BT

MS906BT is the latest addition to the MaxiSys product line of advanced wireless diagnostic devices. It is based on the Android operating system featured with the best possible coverage of OE-level diagnostics and ECU coding capability. Utilizing the powerful Exynos 5260 6-core processor (1.3 GHz quad-core ARM Cortex-A7 + 1.7 GHz dual-core ARM Cortex-A15), an 8” capacitive HD touch screen, and long-distance wireless communication, the MaxiSys MS906BT efficiently provides comprehensive vehicle diagnostics and analysis.

Why Buy Our Autel MS906BT?

Worldwide Vehicle Coverage - MS906BT has better newer vehicle coverage. It can work on over 80+ American, European and Asian vehicles, mostly up to 2018, 2019 and for some up to 2021
Cost-Effective Diagnostic Tool - At about half the price of MaxiSys Elite, you can get the same diagnostic and service functions, it has already saved you hundreds in trips to the mechanic for diagnostics and resets
Upgraded Version for MS906 - MS906BT is not only much more powerful than wired MS906 in vehicle diagnostics and services, but also has twice of MS906’s battery life and supports oscilloscope and digital inspection camera add-ons while MS906 does not
Advanced Functions - MS906BT supports ECU coding(not programming) to help workshops unfold the hidden features or disable the annoying functions etc. to suit car owners customized needs; Bi-directional Control, allows users to send commands to the tested ECUs and monitor the activity of the actuators, such as windows up/ down, switch on/off, etc.
31+ Service Functions - It has 31 service function options, mainly including Oil Reset, EPB service, TPMS ID Relearn, ABS Auto Bleed, SAS Calibration , DPF Regeneration and etc
1-Year Free Software Update - You can perform free software upgrades within one year from the time you register and log in to get the latest features and coverage of the latest models

Autel MS906BT OBD2 diagnostic advanced ecu coding

Autel MaxiSys MS906BT Features:

Unique ergonomic design with rubberized outer protection and a rugged internal housing
Built-in rechargeable lithium-polymer battery for up to 14 hours of continuous operation
USB, audio and auxiliary ports make it easy to connect accessories
Open source Android Operating System for fast boot-up and multitasking
Easy and intuitive navigation makes finding what you need simple and fast
The most extensive complete system coverage for more than 80 US, Asian and European makes and models
Exceptional OE-Level functionality from comprehensive OBD II diagnostics & services to advanced ECU coding
Complete capabilities for codes, live data, active test, ECU information, adaptation, matching, coding etc.
Smart Auto VIN technology for identifying vehicle easily
Automatic system and software updates with real-time push message notifications via internet
Instant remote control tech support anytime, anywhere
Cloud-based MaxiFix online community provides a vast database of diagnostic and repair tips and proven filed fixes
Interactive Data Logging sessions enable direct contact with Autel Technical Support for first-hand troubleshooting of diagnostic bugs and errors
One-stop multitasking designed for ideal management of workshop operations to keep all data files, customer info, and vehicle records well organized
Enhanced wireless BT connectivity between the display tablet and VCI device allows greater mobility and ease at work
Convenient data management system for managing internal program applications and reviewing data

autel ms906bt with mv108 camera features overview

Autel MS906BT Wireless Connection:

Maxisys MS906BT wireless diagnostic interface supports both BT and USB. The BT pairing is recommended as the first choice, and the working range for BT communication is about 164 feet (about 50m). Due to this advantage you can perform vehicle diagnosis freely around the workshop with greater convenience.

MS906BT Full Systems Diagnosis & Services

Doing regular and routine maintenance on a modern car is impossible without a diagnostic system. Even the simplest procedures require the participation of an auto scanner. That's why Autel engineers have been working on them and making them as user-friendly as possible in the new MaxiSys MS906BT. Now you can easily do functions like:

Oil Reset: Reset the oil change calculator in the engine and automatic transmission
EPB: Replacement of brake pads on vehicles with an electric parking brake
SAS: Adaptation of the sensor to the angular position of the steering wheel
DPF: Regeneration of diesel particulate filter
Brake Bleed: ABS Brake Bleeding
IMMO: Immobilizer keys functions(All keys lost, add new keys)
BMS: Battery registration and reset
Seats, Odometer, Injector, CHG tire size, TEC Learn, Suspension, Throttle, WIN OR ROOF, Lang Change, Headlamp.

autel ms906bt all system diagnostic scanner with mv108 camera

Autel MS906BT Digital & Graphical Display of Parameters

Using MaxiSys MS906BT you can display the parameters of the system conveniently. So me parameters are more likely to be monitored in analog form, for example, pressure. Some parameters are more conveniently viewed in graphical form, by observing their change in time (potentiometer, oxygen sensor). Some parameters must be displayed in the graph to observe changes relative to each other (for example, air mass flow and engine speed). Only in Maxisys all these ways of displaying are available for all parameters and all components, regardless of the makes and models of the car.

Autel Maxisys MS906BT Bi-directional Control

Component Test service enables bi-directional control of the ECM so that the ms906bt diagnostic tool is able to transmit control commands to operate the vehicle systems. This function is useful in determining whether the ECM responds to a command well.

Autel Maxisys MS906BT ECU Coding

Coding functions are usually used by advanced specialists. Coding is conditionally divided into two types:

The first is MS906BT computer coding during replacement, commissioning, used to install a new computer in the car. When performing the procedure, the computer is informed of vehicle's VIN, the configuration and other information necessary for correct operation.
The second is the coding of the computer for tuning the body electronics to the user, usually the BCM. The procedure will allow you to offer the customer individual customization of the car for him, locking the doors, setting alarms, the function "lead to home", setting the salon and outdoor lighting, etc.

autel ms906bt scanner ecu coding functions

Autel Maxisys MS906BT Adaptation & Initialization

After replacement, for repair or cleaning of some sensors and many actuators of electronic systems, an adaptation or initialization procedure is required. When performing this procedure, the basic values of their work, the reference point, are established. In a modern car, there are many such elements that require similar procedures, which makes these functions vital for the service. In MaxiSys systems, these procedures are presented at the dealer level.

Autel MS906BT Add-on Functions：

Maxisys MS906BT is a diagnostic scanner with various interfaces that can access to more Add-on like Inspection Camera, HDMI Projector, Phone, PC, USB Memory Stock, Headset, Oscilloscope, Extend SD Card etc.

MS906BT connects to a MV108 / MV105 inspection camera and turns into a video inspection scope, allowing you to examine difficult-to-reach areas normally hidden from sight. It is capable of recording digital still images and videos, which offers you an economical solution to inspect machinery, facilities, and infrastructure in a safe and quick way.

MS906BT works with Autel MP408 oscilloscope providing you an insight to the inner workings of a vehicle’s electronic circuits. Featuring the user-friendly UI design combined with the unrivalled hardware specs, is able to measure and test virtually all the electrical and electronic components and circuits in any modern vehicles.

Autel MS906BT Vehicle Coverage:

For Asian: Acura, Daihatsu, Hyundai, Infinit, Kiat, Mazda, Nissan, Scion, Subaru, Toyota, Manhindra, Proton, Daewoo, Honda, HyundaiCV, Isuzu, Lexus, Mitsubishi, Samsung, Ssang Yong, Suzuki, Fuso, Perodua, Tata
For European: VW, Abarth, AstonMartin, MINI, Sprinster, SKODA, Citroen, Fiat, Lancia, Maserati, Opel, Porsche, SAAB, Vauxhall, Seat, Bugatti, Audi, ForEU, BMW, Alfa, Benz, Maybach, Ferrari, Jaguar, Land Rover, Peugeot, Renault, Smart, Volvo, Lamborghini, Bentley, Rolls-Royce, VW CV, Dacia, LT3
For USA: Chrysler, Dodge, Ford, GM, JEEP

MS906BT Specification:

Operating System	Android™ 4.4.2, KitKat
Processor	Samsung Exynos T5260 6-Core Processor (1.3 GHz quad-core ARM Cortex-A7 + 1.7 GHz dual-core ARM Cortex-A15)
Memory	2 GB RAM & 32 GB ROM
Display	8.0" LED capacitive touch screen with 1024x768P resolution
Connectivity	Wi-Fi (802.11 b/g/n) USB: 2.0, Mini USB 2.0 Wireless BT V2.1+EDR Class1, HDMI 1.4a SD Card (support up to 32 GB)
Camera (rear)	Rear-facing, 8.0 Megapixel AF with Flashlight
Sensors	Gravity Accelerometer, Ambient Light Sensor (ALS)
Audio Input/Output	Microphone, Single Speaker 3-Band 3.5 mm stereo/standard headset jack
Power and Battery	10,000 mAh 3.7 V lithium-polymer battery Charging via 12 V AC/DC power supply
Input Voltage	12 V (9-35 V)
Power Consumption	5 W
Operating Temperature	-10 to 55°C (14 to 131°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Dimensions (W x H x D)	270.8 mm (10.0”) x 176.0 mm (6.9”) x 36.0 mm (1.4”)
Weight	NW: 1.05 kg (2.3lb.)

Autel MS906BT Package List:

Maxisys MS906BT Main Unit
AC/DC Adapter (12V)
Adapter for Chrysler-16 (America Only)
Adapter for GM/Daewoo-12
Adapter for Benz-38
Adapter for Mitsubishi/Hyundai-12+16
Adapter for Honda-3
Adapter for BMW-20
Adapter for Kia-20
Adapter for Nissan-14
Adapter for VW/AUDI-2+2
Cigarette Lighter
MaxiVCI V100
Lighter Fuse
Soft Cloth
Mini USB Cable
User Manual
Packing List
Carrying Case
Quick Reference Guide

Model	MS906S	MS906BT	MK906BT	MS906 Pro	MS906TS
Hardware
CPU	Exynox 5260	Exynox 5260	Exynox 5260	Exynos 8895	Exynox 5260
RAM	2GB	2GB	2GB	4GB	2GB
ROM	64GB	64GB	64GB	128GB	64GB
Battery Capacity	10000 mAh	10000 mAh	10000 mAh	11600 mAh	10000 mAh
Android Version	Android 4.4.4	Android 4.4.4	Android 4.4.4	Android 7.0	Android 4.4.4
Screen Size	8.0 inch	8.0 inch	8.0 inch	8.0 inch	8.0 inch
Screen Resolution	1024*768	1024*768	1024*768	1920*1200	1024*768
Camera	Rear 8.0 Megapixel	Rear 8.0 Megapixel	Rear 8.0 Megapixel	Rear 16.0 Megapixel Front 5.0 Megapixel	Rear 8.0 Megapixel
VCI	V100	V100	V100	V200	V100
Software
Basic Diagnostic Function	√	√	√	√	√
Service	√	√	√	√	√
Special Functions	√	√	√	√	√
Bi-Directional Control(Active Test)	√	√	√	√	√
Online ECU Programming	/	/	/	/	/
Online ECU Coding	/	√(BMW, Porsche, VW)	√(BMW, Porsche, VW)	√(BMW, Porsche, VW)	√(BMW, Porsche, VW)
BMW Brush Hidden	/	√	√	√	√
VW, Audi, Skoda Brush Hidden	√	√	√	√	√
VW, Audi, Skoda, Seat, Bently, Man LD Guide function	√	√	√	√	√
Extended function
Oscilloscope function (requires MP408)	√	√	√	√	√
Endoscope function (requires MV105/MV108)	√	√	√	√	√
Battery Test	√	√	√	√	√
Remote Expert	/	/	/	√	/
Complete TPMS Function
Quick Mode & Advance Mode	/	/	/	/	√
Activate TPMS sensors	/	/	/	/	√
Read sensor data	/	/	/	/	√
TPMS health check	/	/	/	/	√
Read/clear TPMS DTCs	/	/	/	/	√
Scan TPMS sensor ID	/	/	/	/	√
Manual input OE ID into MX-sensor	/	/	/	/	√
Program MX-Sensor by auto creating sensor ID	/	/	/	/	√
Read Sensor ID by OBD and copy ID into MX-Sensor	/	/	/	/	√
Relearn by OBD function	/	/	/	/	√
Relearn procedure guide on the tool	/	/	/	/	√
Read TPMS live data	/	/	/	/	√
Tire Type/Pressure selection	/	/	/	/	√
Other TPMS special functions	/	/	/	/	√
Other Features
Remote Desk	√	√	√	√	√
DoIP/CAN	/	/	/	√	/
D-PDU/RP1210	/	/	/	/	/
Pre & Post Scan	/	/	√	√	√
New Features
Language	Only English	Only English	Multi-Language	Only English	Only English
Autel Cloud Service	√	√	√	√	√
Wifi Printer	/	/	/	√	/

Autel Maxisys MS906BT Automotive Diagnostic Tool Package List
